| STRUCTURE |
Power Shaft |
| TYPE |
Open Type |
| INPUT PART |
Hub 2 places |
| OUTPUT PART |
Shoft |
|
|
| |
| 2개의 전자 클러치와 1개의 내장형 브레이크를 동축상에 조립한 독특한 설계의 다기능
유니트 |
| |
 |
| |
| TYPE |
0.5 |
1.0 |
2.0 |
4.0 |
6.0 |
8.0 |
16 |
19 |
FRICTION TORQUE
( kgㆍm) |
0.5 |
1.0 |
2.0 |
4.0 |
5.5 |
8.0 |
16 |
19 |
RATED VOLTAGE
(DC.V) |
24 |
24 |
24 |
24 |
24 |
24 |
24 |
24 |
HUB(Ødj6)
KEY(bxh1) |
11
4x12.5 |
14
5x16 |
19
5x21 |
24
7x27 |
28
7x31 |
28
7x31 |
38
10x41.5 |
38
10x41.5 |
HUB(Ødj6)
KEY(bxh1) |
38
4x39.5 |
45
5x47 |
55
5x57 |
64
7x67 |
75
7x78 |
75
7x78 |
90
10x93.5 |
90
10x93.5 |
A
B
C
D
E |
100
65
65
90
28 |
125
80
80
110
32 |
150
90
105
140
35 |
190
112
135
175
42 |
215
125
155
200
45 |
230
132
155
200
45 |
290
160
195
240
47 |
290
160
235
295
50 |
F
G
H
I
J1 |
13.5
6.5
105
90
73 |
15
9
130
110
83 |
20
11
160
135
99 |
24
11
185
160
124 |
28
14
230
200
132 |
28
14
230
200
150 |
28
14
270
240
197 |
28
14
280
245
230 |
J2
K
L
M
N |
48
142
211
47
33 |
53
162
246
57
37 |
59
190
294
72
37
|
74
222
358
93
52 |
76
256
408
103
62 |
90
272
440
114
62 |
114
348
555
143
74.5 |
140
287
615
159
74.5 |
O
P
Q1
Q2
U |
M4xD.P8
25
20
3-M4 |
M6xD.P8
30
25
3-M4 |
M6xD.P11
40
30
4-M4 |
M6xD.P11
50
40
4-M4 |
M6xD.P11
55
45
4-M4 |
M6xD.P11
60
50
6-M5 |
M6xD.P17
80
60
4-M6 |
M6xD.P17
90
65
4-M6 |
|
| |
