| STRUCTURE |
Two Shofts |
| TYPE |
Interior Type |
| INPUT PART |
Shoft |
| OUTPUT PART |
Shoft |
|
|
| |
| 클러치, 브레이크를 케이스에 내장한 방적형, 양축구조의 클러치, 브레이크 유니트 |
| |
 |
| |
| TYPE |
0.5 |
1.0 |
2.0 |
2.8 |
4.0 |
6.0 |
8.0 |
16 |
FRICTION TORQUE
( kgㆍm) |
0.5 |
1.0 |
2.0 |
2.8 |
4.0 |
5.5 |
8.0 |
16 |
RATED VOLTAGE
(DC.V) |
24 |
24 |
24 |
24 |
24 |
24 |
24 |
24 |
HUB(Ødj6)
KEY(bxh) |
12
4x13.5 |
14
5x16 |
19
5x21 |
19
5x21 |
24
7x27 |
22
7x25 |
28
7x31 |
38
10x41.5 |
A
B
C
D
E |
100
65
65
90
28 |
125
80
80
110
32 |
150
90
105
140
35 |
172
88
120
172
36 |
190
112
135
175
42 |
204
102
150
209
40 |
230
132
155
200
45 |
290
160
195
240
47 |
F
G
H
I
J |
1.5
6.5
105
90
48. |
15
9
130
110
63 |
20
11
160
135
80 |
Ø7
Ø7
170
154
72 |
24
11
185
160
108 |
Ø12
Ø12
227
202
86.5 |
28
14
230
200
145 |
28
14
270
240
188 |
K
L
M
N |
129
187
25
10 |
166
236
30
12 |
210
295
38
15 |
201
298
44
9.5 |
268
376
50
15 |
249
275
56
12 |
362
490
60
18 |
448
616
80
20 |
|
| |
 |
| |
| TYPE |
20 |
40 |
70 |
100 |
150 |
200 |
FRICTION TORQUE
( kgㆍm) |
19 |
40 |
70 |
100 |
150 |
200 |
RATED VOLTAGE
(DC.V) |
24 |
24 |
24 |
24 |
24 |
24 |
HUB(Ødj6)
KEY(bxh) |
38
10x41.5 |
50
15x55 |
50
15x55 |
55
12x58.3 |
60
18x64.4 |
75
20x79.9 |
| A |
290 |
340 |
475 |
490 |
550 |
640 |
| B |
160 |
180 |
240 |
250 |
260 |
300 |
| C |
195 |
290 |
385 |
400 |
480 |
560 |
| D |
240 |
340 |
475 |
490 |
550 |
640 |
| E |
47 |
120 |
60 |
100 |
100 |
120 |
| F |
28 |
50 |
37 |
40 |
50 |
50 |
| G |
14 |
17 |
17 |
20 |
20 |
23 |
| H |
270 |
350 |
420 |
430 |
490 |
530 |
| I |
240 |
300 |
350 |
370 |
400 |
430 |
| J |
188 |
185 |
240 |
250 |
235 |
230 |
| K |
448 |
500 |
650 |
650 |
670 |
730 |
| L |
616 |
670 |
870 |
870 |
890 |
990 |
| M |
80 |
80 |
100 |
100 |
1oo |
120 |
| N |
20 |
23 |
23 |
23 |
28 |
28 |
|
| |
