MOTOR SPECIFICATION

Frequency

50Hz or 60Hz

Insulation Class

"B","E" standard, "F" Available

Protection Grade

"IP21"standard,"IP54"  Available

Heat Protection

Available With Thermostat or Thermistor

Electronic Regulation

"ACVV","VVVF"Available

Pole

4P, 6P, 4/16P, 6/24P

Power

7.5㎾(10HP)

PERFORMANCE

Efficiency of Power Transfer:78%
Shaft Load:4,000㎏
Noise:65㏈(A)
Vibration:8㎛
Brake:Magnetic Brake
         Non Asbestos
         DC 110V, 0.55A
Weight:650㎏(with motor)
Lubricating oil : ISO VG#320,10ℓ




Hz

RATED SPEED

RATIO

SHEAVE DIA.

MOTOR SPEC.

RATED LOAD

ROPE

ROPING

60

30m/min

1/59

Ø500

7.5㎾×6p

1050㎏

ø12×4 (pitch 19)

1:1

45m/min

7.5㎾×4p

850㎏

60m/min

1/51

Ø550

750㎏

90m/min

2/33

500㎏

105m/min

Ø630

450㎏

120m/min

Ø700

400㎏

50

30m/min

1/52

Ø500

7.5㎾×6p

1050㎏

45m/min

7.5㎾×4p

850㎏

60m/min

1/42

Ø550

750㎏

90m/min

1/33

Ø630

500㎏

105m/min

2/41

Ø480

450㎏

120m/min

Ø550

400㎏
