MOTOR SPECIFICATION

Frequency

50Hz or 60Hz

Insulation Class

"B","E" standard, "F" Available

Protection Grade

"IP44"standard,"IP54" Available

Heat Protection

Available With Thermostat or Termistor

Electronic Regulation

"ACVV","VVVF"Available

Pole

4P,6P,4/16P,6/24P

Power

7.5㎾(10HP), 9㎾(12HP)

PERFORMANCE

Efficiency of Power Transfer:85%
Shaft Load:4,500㎏
Noise:58㏈(A)
Vibration:7㎛
Brake:Magnetic Brake
         Non Asbestos
         DC 110V, 1.5A
Weight:500㎏(with motor)
Lubricating oil : ISO VG#320,7ℓ






Hz

RATED SPEED

RATIO

SHEAVE DIA.

MOTOR SPEC.

RATED LOAD

ROPE

ROPING

60

30m/min

1/58

Ø480

7.5㎾×6p(9㎾)

1050(1250)㎏

ø12×4
(pitch 19)

1:1

45m/min

7.5㎾×4p(9㎾)

950(1050)㎏

60m/min

1/49

Ø550

800(950)㎏

90m/min

2/59

Ø480

550(650)㎏

105m/min

Ø550

450(550)㎏

120m/min

2/49

400(500)㎏

50

30m/min

1/58

Ø550

7.5㎾×6p(9㎾)

1050(1250)㎏

45m/min

7.5㎾×4p(9㎾)

950(1050)㎏

60m/min

1/38

Ø500

800(950)㎏

90m/min

2/49

Ø480

550(650)㎏

105m/min

2/43

Ø500

450(550)㎏

120m/min

Ø550

400(500)㎏
